KLQ6906YEV
MAIN PARAMETERS
| BUS Model | KLQ6906YEV (9.0 METER) |
| Standard seat number | 39+1+1 (2x2 seat) |
| Overall dimensions | mm 8995x2550x3505 |
| Manufacturer’s max. total mass | kg 13200 |
| Overhang front/rear | mm 1855/2490 |
| Wheelbase | mm 4650 |
| Max speed | km/h 100 |
| Kerb mass | kg 10000 |
| Batter Capacity | CATL charging power battery 255.02kwh |
| Driver Motor | Prestolite Motor (2800N.m) | Drive Motor Controller | Higer Motor Controller |
| Mileage | With Aircon on and traffic road, estimated mileage is 250-300km |
| Rated Power (kw) | 260 |
| Suspension | Air suspension | Front Axle | Fangsheng front axle 4.2 tons, disk brake, Sweden SKF maintenance-free bearing |
| Rear Axle | Fanghseng rear axle, 9.2 Tons, drum brake, axle ration 5.13; Sweden SKF maintenance –free bearing |
| Propeller shaft | Strengthen propeller shaft |
| Brake | Wabco ABS, Dual-circuit service brake, spring energy parking brake, with electronic hand brake |
| Steering | Bosch Power Steering |
| Fan system | ATS (Automatic temperature control system), smart fan drive |
| Tires | Doublecoin 10R22.5 |
| Others | With ABS sensor, T-box |
| A/C | NTC Aircon, 32000kcal/h, |
| Body type | Semi-monoque, single front door, no middle door, no emergency door, no CR |
| Side mirror | Rabbit Ear type rear view mirror, electric control |
| Luggage compartment door | Manual Lift-up luggage compartment door |
| Seats | 2x2 seat (leatherette), 2-point seatbelt, with USB charger |
| Passenger Door | Single door with remote control function |
| Windows | Sealed side window glass, light grey glass, 2 piecese windshield |
| Bus Reverse Monitor | Color Reverse camera, with reverse radar; Equipped with 4 cameras and 1T storage |
| Floor | Anti-attrition fllor leatheroid, flat floor | Others | Luxury luggage rack with reading lamps ; Digital Clock; Double long lights, LED; Cloth folding window curtain; 1 emergency roof exit; Automatic Fire extinguisher device in engine compartment; safety hammer; Equipped with DMS (Driver monitoring system for anti-fatigue driving) 2pcs windshield glass |
click any of the images above to enlarge
The manufacturer reserves the right to change the technical specs for better improvement without prior notice.
